PCB · 26S7X8156
IDU Main PCB Board 1.0 Ton Non-Inverter
Central logic motherboard relay board for 1.0 Ton split ACs.
₹5,99918% GST extra · Nos.
Availability, site conditions, additional work and final terms are confirmed before acceptance.
- SKU
- 26S7X8156
- Category
- PCB
- Capacity / size
- 1.0 Ton
- Warranty
- 90 days
- Unit
- Nos.
- Tax treatment
- 18% GST extra
Item scope
- Supply of the named item
- Basic visual condition check
- Compatibility confirmation before dispatch where applicable
Exclusions / additional work
- Installation unless explicitly included
- Unlisted accessories or consumables
- Manufacturer warranty beyond the stated record
Selection & fulfilment
- Step 1: Input line voltage, neutral-earth ground and ripple check
- Step 2: Microcontroller logic and IPM transistor bank diagnostic
- Step 3: Installation of factory-sealed board with heatsink paste
- Step 4: Compressor frequency ramp-up and error code clearance test
Catalogue guide
Illustrated views explain the listed scope. They are not five independently photographed products or project sites.
Short catalogue overview
Illustrative catalogue animation with gentle original audio. Use the player volume control to adjust or mute.
Before you book or order
Confirm compatibility, exact item, coverage and final scope with our team. Listed warranty: 90 days.
